Rider · Heavy-duty

SPECIFICATION

Rider heavy-duty
key specifications

Deployed dimensions: 1050 × 870 × 1700 mm
Folded dimensions: 1230 × 870 × 530 mm
Net weight, with battery: 43.65 kg
Payload: 120 kg
Range: 16 km
Operating time: ≥ 4 h
Operating temperature, standard: −10 to +40 °C
Operating temperature, low-temp option: −40 to +60 °C
Ingress protection: IP65
Max. single-side obstacle: ≤ 285 mm
Max. trench width: ≤ 370 mm
Max. climbing angle: 33°
Overall assistance efficiency: 86%
Maximum assistance efficiency: 97%
Control modes: Off-road / level ground / slope
Max. speed, level / off-road / slope: 16 / 11 / 6.5 km/h
Human-machine connection time: 2.4 s
Human-machine release time: 0.6 s

WHAT IT DOES

120 kg, 33°,
and IP65 on the enclosure.

120 kg of payload, 16 km of range

The heavy-duty build is rated to 120 kg and 16 km, with at least 4 hours of operating time. That is a full rescue pack, a tool load or a water container, moved by one person.

Bigger footprint, same idea

Deployed it measures 1 050 × 870 × 1 700 mm; folded, 1 230 × 870 × 530 mm at 43.65 kg with the battery in. The taller stance keeps the load clear of undergrowth while the folded height still fits a vehicle.

Three modes, three ceilings

16 km/h on level ground, 11 km/h off-road and 6.5 km/h in slope mode. Off-road mode is the default on broken ground, where the higher torque matters more than speed.

Steps 285 mm, spans 370 mm

Rated to a 285 mm obstacle on one side and a 370 mm trench, with a 33° climb. Overall assistance efficiency is 86%, rising to 97% at peak.

Sealed, and rated for cold

IP65 on the enclosure. The standard build runs from −10 °C to +40 °C; a low-temperature version covers −40 °C to +60 °C. The operator link connects in 2.4 s and releases in 0.6 s.

IN THE FIELD
