Rider · Light-duty

SPECIFICATION

Rider light-duty
key specifications

Deployed dimensions: 1400 × 640 × 1100 mm
Folded dimensions: 820 × 640 × 520 mm
Net weight: 30 kg
Payload: 80 kg
Range: 18 km
Operating time: ≥ 5 h
Operating temperature: −40 °C to +60 °C
Wading depth: 150 mm
Ingress protection: IPX5
Battery level: Percentage shown on display
Max. single-side obstacle: ≤ 240 mm
Max. trench width: ≤ 300 mm
Max. climbing angle: 30°
Overall assistance efficiency: 88%
Maximum assistance efficiency: 97%
Control modes: Level ground / off-road / slope
Max. speed, level / off-road / slope: 15 / 10 / 6 km/h
Human-machine connection time: 2.4 s
Human-machine release time: 0.6 s

WHAT IT DOES

80 kg, 18 km,
and it folds into a boot.

Folds into 820 × 640 × 520 mm

Folded, the machine measures 820 × 640 × 520 mm and weighs 30 kg — it goes in the back of a car or on a shelf between jobs. Opened out it is 1 400 mm long, 640 mm wide and 1 100 mm high, carrying 80 kg.

18 km and five hours on a charge

Range is rated at 18 km with at least 5 hours of operating time. Battery state is shown as a percentage on the display rather than as a bar, so you know before you leave whether the return leg is covered.

Three drive modes, three speed ceilings

Level ground up to 15 km/h, off-road at 10 km/h and slope mode at 6 km/h. Each mode sets its own ceiling, so the machine stays predictable when the surface changes under load.

Climbs 30°, steps 240 mm, spans 300 mm

Rated to a 30° climb, a 240 mm obstacle on one side and a 300 mm trench. Assistance efficiency is 88% overall and 97% at peak — the machine is doing most of the work, not you.

Follows in 2.4 s, releases in 0.6 s

The operator link connects in about 2.4 seconds and lets go in 0.6. The build is rated from −40 °C to +60 °C, takes 150 mm of water and carries an IPX5 enclosure.
